Сетевой стандарт

IEEE 802.11a, 802.11b, 802.11g, 802.11d, 802.11h, 802.11n

Wired/Switching/Routing

IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification и IEEE 802.1Q VLAN tagging

Data RFC

• RFC 768 UDP
• RFC 791 IP
• RFC 792 ICMP
• RFC 793 TCP
• RFC 826 ARP
• RFC 1122 Requirements for Internet Hosts
• RFC 1519 CIDR
• RFC 1542 BOOTP
• RFC 2131 DHCP

Статус LED

Внешний LED индикация: Power, PoE, Diag, Speed, LAN

Стандарты безопасности

• Wi-Fi защищеный доступ (WPA)
• IEEE 802.11i (WPA2, RSN)
• RFC 1321 MD5 Message-Digest Algorithm
• RFC 2104 HMAC: Keyed Hashing for Message Authentication
• RFC 2246 TLS Protocol Version 1.0
• RFC 3280 X.509 PKI Certificate and CRL Profile

• WEP and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys)
• Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit
• Advanced Encryption Standard (AES): CCM, Counter Mode with Cipher Block Chaining Message Authentication Code Protocol (CCMP)

• IEEE 802.1X
• RFC 2548 Microsoft Vendor-Specific RADIUS Attributes
• RFC 2716 PPP EAP-TLS
• RFC 2865 RADIUS Authentication
• RFC 2866 RADIUS Accounting
• RFC 2867 RADIUS Tunnel Accounting
• RFC 2869 RADIUS Extensions
• RFC 3576 Dynamic Authorization Extensions to RADIUS
• RFC 3579 RADIUS Support for EAP
• RFC 3580 IEEE 802.1X RADIUS Guidelines
• RFC 3748 Extensible Authentication Protocol
• Web-based authentication

• SNMP v1, v2c, v3
• RFC 854 Telnet
• RFC 1155 Management Information for TCP/IP-Based Internets
• RFC 1156 MIB
• RFC 1157 SNMP
• RFC 1213 SNMP MIB II
• RFC 1350 TFTP
• RFC 1643 Ethernet MIB
• RFC 2030 SNTP
• RFC 2616 HTTP
• RFC 2665 Ethernet-Like Interface types MIB
• RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual LAN Extensions

Интерфейсы управления

• Designed for use with Cisco Wireless Control System
• Web-based: HTTP/HTTPS individual device manager
• Command-line interface: Telnet, SSH, serial port

Интерфейсы и индикаторы

• Console port: RS-232 (DB-9 male/RJ-45 connector included)
• Network: Eight 10/100 Mbps Ethernet (RJ-45) including two 802.3af or Cisco PoE ports rated for use with Cisco Aironet lightweight access points
• LED indicators: Link Activity (each 10/100 port), Power, Status, Alarm, Access Point Joined

4.45 x 20.04 x 17.45 мм

Вес: 4.0 lbs

Температура хранения: -25º to 70ºC

36-57VDC
