Характеристики решения Extreme Networks Purview
Physical Specifications
- Height: 1.75” (4.45 cm) – 1U
- Length: 27.95” (70.9 cm)
- Width 16.93” (43 cm)
- Weight 31.8 lbs (14.4 kg)
Power
- Wattage: 750 Watt (max), each power supply
- Voltage:110/240 VAC;
- Frequency 47- 63Hz
Environmental Specifications
- Operating Temperature: 10° to 35°C (50° to 95°F)
- Storage Temperature: -40° to 70°C (-40° to 158°F)
- Operating Humidity: 5% to 90% (noncondensing)
Standards Compliance
Regulatory/Safety:
- UL60950 – CSA 60950 (USA/Canada)
- EN60950 (Europe)
- IEC60950 (International)
- CB Certificate & Report, IEC60950 GS Certification (Germany)
- GOST R 50377-92 – Certification (Russia)
- Ukraine Certification (Ukraine)
- CE – Low Voltage Directive 2006/95/EC (Europe)
- IRAM Certification (Argentina)
Emissions/Immunity
- FCC/ICES-003 – Emissions (USA/Canada)
- CISPR 22 – Emissions (International)
- EN55022 – Emissions (Europe)
- EN55024 – Immunity (Europe)
- EN61000-3-2 – Harmonics (Europe)
- EN61000-3-3 – Voltage Flicker (Europe)
- CE – EMC Directive 2004/108 EC (Europe)
- VCCI Emissions (Japan)
- AS/NZS 3548 Emissions (Australia/New Zealand)
- BSMI CNS13438 Emissions (Taiwan)
- GOST R 29216-91 Emissions (Russia)
- GOST R 50628-95 Immunity (Russia)
- Ukraine Certification (Ukraine)
- KC Certification (Korea)
Purview Engine Virtual Appliance
Packaged in the .OVA file format defined by VMware and must be deployed on a VMware ESX™ 4.0, 4.1, 5.0, or 5.1 server or ESXi™ 4.0, 4.1, 5.0, or 5.1 server with a vSphere™ 4.0, 4.1, 5.0, or 5.1 client.
Virtual appliance requires 24 GB of memory, twenty-four CPUs, two network adapters, and 2 TB of thick-provisioned hard drive space.
